Building a Cedar Pergola for Shade and Shelter

Why Cedar Earns Its Place in a British Garden

Western red cedar has been the material of choice for garden structures in damp climates for good reason. Its timber contains natural oils and acids that make it resistant to rot and insect attack, so it sits comfortably in the British weather without the annual ritual of brushing on preservative. Left untreated, it weathers to a soft silver-grey over two or three seasons; given a coat of UV-protective oil, it holds a warm reddish-brown for far longer. Either way, it stays stable, warping and twisting far less than many cheaper softwoods.

It is a light timber, too, which matters when you are lifting a four-metre beam above your head on a windy Saturday. The trade-off is cost, so it pays to buy from a timber merchant who can supply consistent grades and, ideally, let you pick through the stock.

Deciding Where It Goes and How Big It Should Be

Position comes before design. Watch your garden across a full day before you commit: a pergola sited where it will shade a south-facing patio between noon and four o'clock will earn its keep, but one plonked in the sunniest spot will simply add clutter.

As a rule of thumb for a seating area, allow at least 3m x 3m, with posts spaced so nobody walks into them. Height matters more than most people expect — set the lowest beam at 2.2m to 2.4m so you can walk beneath it without ducking, and higher still if you plan to grow a vigorous climber overhead.

Before you dig anything, check the planning position:

• Most garden pergolas fall under permitted development, but height limits apply if the structure sits within 2m of a boundary — typically 2.5m to the highest point.
• Pergolas forward of the principal elevation (between the house and the road) usually need permission.
• If you are in a conservation area, a listed building or a flat, ask the local planning authority first.
• Attaching a ledger board to a house wall may raise party wall considerations with a neighbour.

Getting the Footings Right

This is the part people rush, and it is the part that decides whether your pergola is still square in ten years. Cedar is durable, but it still rots where it sits permanently in wet ground.

For posts set into the ground, dig holes around 600mm deep and 300mm square, wider than the post itself, and fill with a concrete mix. Slope the top of the concrete slightly away from the post so water runs off, and stand the post on a bed of concrete or a paving slab at the bottom of the hole so it never sits directly on soil. Use 100mm x 100mm posts for a domestic pergola, or 150mm x 150mm if the span is generous or the site is exposed.

Where you are building over an existing patio, bolt galvanised or stainless steel post bases to the slabs instead. This keeps timber clear of standing water and is far less disruptive, though it relies on the slabs being properly bedded.

Whichever route you take, brace the posts plumb and set them to a string line before the concrete goes off. Check the diagonals across the corners — if they match, the frame is square.

Fixings, Joints and Wind Loading

Cedar's natural acidity attacks mild steel and ordinary galvanised fixings, which leads to black staining and, eventually, corrosion. Use stainless steel A2 or A4 screws, bolts and nails throughout, and pre-drill every hole near an end grain to avoid splitting.

For a robust frame:

• Run two parallel beams across the tops of the posts, sandwiching each post between them and bolting through with M10 or M12 stainless bolts.
• Space rafters at 400mm to 600mm centres — tighter for more shade, wider for a lighter, airier feel.
• Notch rafters over the beams or sit them in stainless joist hangers; simply screwing them to the top of a beam gives you very little resistance to uplift.
• Fit diagonal braces at each corner. A pergola is essentially a sail, and bracing is what stops it flexing in a winter gust.

Roofing, Planting and the Finishing Touches

A pergola with nothing overhead offers dappled light at best. To get genuine shelter, consider close-set rafters, a slatted roof with adjustable louvres, or a retractable canopy in a weatherproof fabric. A polycarbonate sheet on part of the roof will keep a bench dry through the winter, though it does need a fall of at least 1:40 so water runs off rather than pooling.

Climbers are what soften the whole structure. Good choices for British gardens include wisteria on a sturdy frame, jasmine for scent, and grape vines for autumn colour. Keep plants clear of the joints and check ties each spring, as stems thicken quickly.

Looking After It

Cedar needs remarkably little, but a small amount of attention goes a long way. Clear fallen leaves from the roof each autumn, check bolt tightness after the first winter and again every couple of years, and re-oil the timber every two to three years if you want to keep its colour. Inspect the base of each post annually for softness — that is where trouble starts, and catching it early is far cheaper than replacing a leg.

Build it properly at the ground, and a cedar pergola becomes one of the hardest-working features in the garden: shade in July, shelter in November, and a frame that quietly improves as the planting matures around it.
